| Display Specifications |
|
| Display |
15″ Color TFT Panel mount touch Monitor |
| Model Name |
AXD-15OPIPPM07-T1 |
| Active Display Area (mm) |
304.1(H)x304.1(V) |
| Pixel Pitch (mm) |
0.297(H)x0.297(V) |
| Resolution (Pixel) |
XGA (1024X768) 262K/16.2M Color |
| Brightness (CD/m^2) |
800nits |
| Contrast Ratio |
600:1 |
| Viewing Angle (CR >=10) |
160/140 |
| Power consumption |
23.3W typical, normal operation |
| Touch Screen |
Resistive;RS232/USB(Optional) |
| OSD Control |
On the back side |
| I/O Connectors |
1x12v,1XVGA,DVI-D |
| Power Input |
DC 12V,4A 48W |
| Mechanical Specifications |
|
| Construction |
Steel Metal chassis & Black Color |
| Dimensions |
398.0 x 295.0x 48 (mm) |
| Mounting |
Edge fixing holes, vesa mounting on the backside |
| Power source |
AC 100~240V/ 12V DC |
| Environment Specifications |
|
| Operating Temperature |
-10~70℃ |
| Storage Temperature |
-20~80℃ |
| Rating |
Facilitate installation of the demolition,solid portfolio |
| Ordering Information |
15” Panel mount touch LCD Monitor with VGA input and power adapter |
15 Inch Rack Mount TFT Resistive Touch LCD Monitor For Outdoor CNC 12VDC
Brand :
Screen Size:15
Screen format: 4:3
Display Resolution(pixel):1280×1024
Contrast Ratio:600:1
Brightness:800cd/m^2
Storage temperature : -10℃~70℃
Input signal: VGA DVI
Power Input: DC 12V
Touch Type: Resistive touch
